Nokia 5800

IMG_0776

Software

  • Symbian Bible
  • WorldMate
  • Opera Mobile (Full web browser)
  • Opera Mini (Low bandwidth web browser)
  • AutoInstaller (Installs many softwares automatically)
  • Putty Touch (SSH client)
  • QScanner (2D and 1d barcode scanner )
  • Gravity (twitter client)

Tips

  • *#7370# = HR Hard Reset
  • *#7780# = SR Soft Reset
  • *#0000# = Firmware info
  • *#2820# (*#BTA0#) Bluetooth device address.
  • *#62209526# (*#MAC0WLAN) View MAC address of WLAN adapter.
  • *#92702689# (*#WAR0ANTY#) life timer information.

Jailbreaking

After jailbreaking, there are several things you can do: mute camera sound, install any program (including the one that requires high capabilities).

For older firmware, a phone software is avaibale (Hello OX) to jailbreak (requires developer certificate which you can get from some Chinese site). For later versions, we will need desktop software to modify ROM. The ROM modification uses tools that are not freely available.

After jailbreaking, it will be possible to install RomPatcher or RomPatcherPlus that will enable us to disable or enable certain OS features.

Silencing Camera, Video, Recording Tones

You need to jailbreak or use other camera apps to silent the camera.

Specifications

Taken from wikipedia

  • Screen: nHD 640 x 360 pixels, 3.2 inch 16:9 widescreen, (16.7 million colours)
  • Camera: 3.2 Megapixels, Carl Zeiss AG optics with autofocus and dual LED flash
  • Second camera: Front camera for video calls
  • Operating system: Symbian OS 9.4 + S60 platform 5th Edition (s60v5), Firmware version 50.0.005
  • Input: Touchscreen with Nokia Dynamic Intelligent Layouts, proximity sensor, accelerometer
  • CPU: ARM11 @ 434 Mhz
  • Memory: 128 MB SDRAM, 256 MB NAND, 81 MB Internal User Storage
  • Memory card: max. 16 GB microSDHC (32 GB unofficial), 8 GB card included
  • Networks: GSM, EGPRS, WCDMA, HSDPA, A-GPS
  • Connectivity: Bluetooth 2.0 (EDR/A2DP), WLAN (802.11 b/g), MicroUSB 2.0; 3.5 mm headphone and video-out jack
  • Battery: BL-5J (3.7V 1320mAh); 2 mm charging connector
  • Physical size: 111 × 51.7 × 15.5 mm
  • Weight: 109g
  • Form factor: Candybar
  • Media: AAC, AAC+, eAAC+, MP3, MP4 (MPEG-4 Part 2 VGA / H.264 QVGA), M4A, WMA, AMR-NB, AMR-WB, Mobile XMF, SP-MIDI, MIDI Tones (poly 64), RealAudio 7,8,10, True tones, WAV, but not Ogg files.
